ASTM 1017 Erw Precision Steel Tubes 7mm Hot Rolled For Infrastructure

Place of Origin	China
Brand Name	BAO STEEL
Minimum Order Quantity	Negotiable
Price	Negotiable
Packaging Details	Export standard package: bundled ,wooden box, suit for all kinds of transport,or be required
Delivery Time	15-25 work days
Payment Terms	T/T
Supply Ability	25000 ton/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Certification	API,CE,ISO	Application	Structure Pipe,Hydraulic Pipe,Construction,Fluid Pipe,Oil Pipe
Standard	ASTM,DIN,GB,JIS,API	Thickness	2 - 50 Mm,0.1mm-60mm,1 - 8 Mm
Technique	Cold Drawn,Hot Rolled	Surface Treatment	Galvanized,customerized
Secondary Or Not	Non-secondary	Product Name	Steel Tubes
Type	Welded Or Seamless Tube
High Light	ASTM 1017 Erw Precision Steel Tubes , Erw Precision Steel Tubes 7mm , Precision Steel Tubes ASTM 1017

Leave a Message

Product Description

JIS G3445 455 Cold Rolled Carbon Precision Steel Pipe Tube

Carbon steel piping is a durable material made from carbon steel, a steel alloy with iron and carbon. Because of its strength and ability to withstand stress, carbon steel pipe is used in a variety of heavy-duty industries like infrastructure, ships, distillers, and chemical fertilizer equipment.

Standard

Standard	Material Chemical Composition (%)
Standard	Steel Grade	Material Number	C	Si	Mn	P	S	Cr	Mo
DIN 2391	ST35	1.0308	≦ 0.17	≦ 0.35	≧0.04	≦0.025	≦0.025	－	－
	ST45	1.0408	≦ 0.21	≦ 0.35	≧0.04	≦0.025	≦0.025	－	－
	ST52	1.058	≦ 0.22	≦ 0.55	≦1.60	≦0.025	≦0.025	－	－

Standard	Material Chemical Composition (%)
Standard	Steel Grade	Material Number	C	Si	Mn	P	S	Cr	Mo
DIN1629	ST37	1.0254	≦ 0.17	≦ 0.55	≦1.60	≦0.04	≦0.04	－	－
	ST44	1.0258	≦ 0.21	≦ 0.55	≦1.60	≦0.04	≦0.04	－	－
	ST52	1.0421	≦ 0.22	≦ 0.55	≦1.60	≦0.04	≦0.035	－	－
DIN1630	ST37.4	1.0255	≦ 0.17	≦ 0.35	≧0.035	≦0.04	≦0.04	－	－
	ST44.4	1.0257	≦ 0.21	≦ 0.35	≧0.04	≦0.04	≦0.04	－	－
	ST52.4	1.0281	≦ 0.22	≦ 0.55	≦1.60	≦0.04	≦0.035	－	－

Standard	Material Chemical Composition (%)
Standard	Steel Grade	Material Number	C	Si	Mn	P	S	Cr	Mo
EN10305-1 EN10305-4	E235	1.0308	≦ 0.17	≦ 0.35	≧0.04	≦0.025	≦0.025	－	－
	E255	1.0408	≦ 0.21	≦ 0.35	≧0.04	≦0.025	≦0.025	－	－
	E355	1.058	≦ 0.22	≦ 0.55	≦1.60	≦0.025	≦0.025	－	－

Standard	Material Chemical Composition (%)
Standard	Steel Grade	Material Number	C	Si	Mn	P	S	Cr	Mo
ASTM A519	1010	-	0.08-0.13	-	0.3-0.6	≤0.04	≤0.05	-	-
	1020	-	0.18-0.23	-	0.3-0.6	≤0.04	≤0.05	-	-
	1045	-	0.43-0.50	-	0.6-0.9	≤0.04	≤0.05	-	-
	4130	-	0.28-0.33	0.15-0.35	0.40-0.60	≤0.04	≤0.05	0.8-1.1	0.15-0.25
	4140	-	0.38-0.43	0.15-0.35	0.75-1.0	≤0.04	≤0.05	0.8-1.1	0.15-0.25

Standard	Material Chemical Composition (%)
Standard	Steel Grade	Material Number	C	Si	Mn	P	S	Cr	Mo
JIS G3445	SKTM 12C	－	≦ 0.12	≦ 0.35	≦ 0.60	≦0.04	≦0.04	－	－
JIS G3445	STKM 13C	－	≦ 0.25	≦ 0.35	0.3-0.9	≦0.04	≦0.04	－	－

Standard	Material Chemical Composition (%)
Standard	Steel Grade	Material Number	C	Si	Mn	P	S	Cr	Mo
GB/T 8162 GB/T 8163 GB/T 3639	10	－	0.07-0.14	0.17-0.35	0.35-0.65	≦0.035	≦0.04	－	－
	20	－	0.17-0.23	0.17-0.37	0.35-0.65	≤0.035	≤0.035	－	－
	45	－	0.42-0.50	0.17-0.37	0.50-0.80	≤0.035	≤0.035	－	－
	Q345B	－	≤0.20	≤0.50	≦1.70	≤0.035	≤0.035	－	－

Delivery Condition: BKW, BKS, +LC, +SR
ID tolerance can minimized to +/-0.02mm
OD: 5- 250mm
ID: 3- 200mm

Equivalent Material referance:
GB	TOCT	ASTM	BS	JIS	NF	DIN
10F		1010	040A10		XC10
10	10	10,101,012	045M10	S10C	XC10	C10,CK10
20	20	1020	050A20	S20C	XC18	C22,CK22
45	45	1045	080M46	S45C	XC45	C45,CK45
30CrMo	30XM	4130	1717COS110	SCM420	30CD4
42CrMo		4140	708A42		42CD4	42CrMo4
			708M40
35CrMo	35XM	4135	708A37	SCM3	35CD4	34CrMo4

Product Paramenters

Product name	Carbon Steel Round Pipe
Standard	AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc
Material Grade	Q195, Q215, Q235, Fe310, Fe360, St33, St37-2, SS330, SS400, S235, S275, S355, ASTM 1010, ASTM 1017, ASTM 1020 Q195 = S195 / A53 Grade A Q235 = S235 / A53 Grade B / A500 Grade A / STK400 / SS400 / ST42.2 Q345 = S355JR / A500 Grade B Grade C
Length	2-12m or as request
Thickness	1.2-30 mm or as customized
Outer Diameter	10mm-600mm or as customized
Thickness Tolerance	±0.01mm
Technique	Hot rolled / cold rolled
Surface Treatment	Bared, Black Painted, Galvanized, Oiled or to your requirements
Sample	Can provide samples
Application	1. Fluid pipe 2. Power Plant 3. Structure pipe 4. High and low pressure Boiler tube 5. Seamless pipe /tube for petroleum cracking 6. Conduit pipe 7. Scaffolding pipe pharmaceutical andship, building etc.
Processing Service	Welding, Punching, Cutting, Bending, Decoiling.ect
MOQ	1 ton
Payment	Our usual payment methods are T/T, L/C, D/A, D/P, Western Union, MoneyGram (30% deposit).
Advantages	1). For liquid transport 2). Applied chemical, natural gas gas transportation 3). Used for piling pipes, construction pipes 4). Agricultural irigation, urban construction, etc
Certificate	ISO, CE,.ect.
All sizes can be customized according to customer requirements.
